Light output: 1000 ANSI lumens (Comparable with 5000 Lumen lamp projectors)

Aspect ratio: 16:9

Resolution: 1920 x 1080

Beam angle: 17°

Throw ratio: 3.5:1

Contrast ratio: 500:1

Display colours: 16.7 million colours

Optional wide lens: 26°

Throw ratio wide lens: 2.3:1

Colour mixing mode RGB/CMY

White light: Variable CCT 3.200K - 9.500K

Colour effect wheel with wide range of in-built effects (colour transitions and cross-fades, multiple colour images, rainbow effects)

Digital gobo wheel 1: with standard gobos, images and videos

Digital gobo wheel 2: with user´s gobos, images and videos

Gobo rotation and indexing

Video on/off and speed control

Live input via external High Definition Multimedia Interface

Effect wheel with wide range of graphic effects (Kaleidoscopic effect, fish eye, iris, zoom, swirl effect, pixelation effect, cross-stitching, posterization, and more…)

Effect speed control

Horizontal/Vertical keystoning

ADM™ Automatic distance meter: On request

Grey box correction

Motorized focus

Pre-programmed random strobe & pulse effects

Dimmer: 0 - 100%

Setting & Addressing: Robe Graphic Touch Screen (50x40mm / 1.97" x 1.57")

Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN

REAP™ - Robe Ethernet Access Portal

Wireless CRMX™ technology from Lumen Radio - on request

DMX Protocol modes: 2

Control channels: 25, 33

RTC (real-time clock): built-in device to keep track of actual time in order to start and stop playback at given time

Stand-alone operation

Upload and projection of custom artwork, still photographs and videos from USB memory stick

Remote content management

Internal storage: high speed internal memory for user content – 32 GB

NAS client: automatic content synchronization tool

Live video stream: from remote source

Pan movement: 540°

Tilt movement: 250°

Movement control: Standard and Speed

Controllable speed of Pan/Tilt movement

Automatic Pan/Tilt position correction

Raspberry Pi, Model 3, 1GB

Linux OS

Maximum ambient temperature: 40°C (104°F)

Maximum surface temperature: 60°C (140°F)

Minimum operating temperature: 0°C (32°F)

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 140 W

Power connector in/out: Neutrik powerCON TRUE1 in/out

DMX and RDM data in/out: Locking 5-pin XLR

Ethernet port in/out: RJ45

2x USB 2.0 connector (series A)

External video input 1x High Definition Multimedia Interface

Embedded Ethernet switch 10/100 Mbps: 1 x in / 1 x out

CE Compliant

cETLus Compliant

Height: 508 mm (20") - head in vertical position

Width: 328 mm (12.9")

Depth:

• 283 mm (11.14") – base with stage covers

• 364 mm (14.3") – base with installation covers

Weight: 12 kg (26.5 lbs)

Mounting points: 1 pair of 1/4-turn locks

1x Omega adaptor with 1/4-turn quick locks

Universal operating position

Safety cable attachment point

User Manual

Omega Adaptor CL-regular 2 pcs: 10980033

Power cord including powerCON TRUE1 In connector

Doughty Trigger Clamp: 17030386

CRMX Wireless Receiver: 13030894

Safety wire 36 kg: 99011963

Wide angle lens: 26° 10980547

Installation base covers black: 10980548

Ceiling mounting kit black: 10980551

Daisy Chain powerCON TRUE1 In/Out, EU, 2m, Indoor: 13052439

Daisy Chain powerCON TRUE1 In/Out, US, 2m, Indoor: 13052440

Daisy Chain powerCON TRUE1 In/Out, EU, 5m, Indoor: 13052444

ADM™ Automatic distance meter: 10980549

Single Top Loader Case: 10120265

Quad Top Loader Case: 10120266

Foam Shell: 20020378

ProMotion™ is a Trademark of Robe lighting s. r. o.

ProMotion™ is patented by Robe lighting s. r. o. and protected by one or more pending or issued patents
